1269405
Specification
- Housing material
- Metal
Other features
- Depth
- 180 mm
- Height
- 44 mm
- Width
- 294 mm
- Unit Box Width
- 0.25
- Unit Box Length
- 0.405
- Unit Box Height
- 0.08
- Category Code
- SWI
- Model name
- TL-SG1008MP
- Model
- TL-SG1008MP
- Form Factor
- 1U
- Switch type
- Unmanaged
- Switching capacity
- 16 Gbit/s
- Forwarding rate
- 11.904 Mpps
- Number of fans
- 1 fan(s)
- Auto-negotiation
- Yes
- Power source
- AC/PoE
- Unit Calculated Volume
- 0.0081 cubm
- Unit Calculated Weight
- 2.23 kg
- Units per Shipping Box
- 1
- Summary
- TP-Link TL-SG1008MP. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8. Full duplex. MAC address table: 4000 entries, Switching capacity: 16 Gbit/s. Networki
- Product colour
- Black
- AC input frequency
- 50/60 Hz
- AC input voltage
- 100 - 240 V
- Package depth
- 400 mm
- Package height
- 80 mm
- Package type
- Box
- Package weight
- 2110 g
- Package width
- 250 mm
- Cables included
- AC
- Sustainability compliance
- Yes
- Power consumption (max)
- 173.65 W
- Operating relative humidity (H-H)
- 10 - 90 %
- Operating temperature (T-T)
- 0 - 40 °C
- Storage relative humidity (H-H)
- 5 - 90 %
- Compliance certificates
- CE/Federal Communications Commission (FCC)/RoHS
- Storage temperature (T-T)
- -40 - 70 °C
- Harmonized System (HS) code
- 85176990
- LED indicators
- Yes
- Heat dissipation
- 592.15 BTU/h
- User guide
- Yes
- Power supply included
- Yes
- Copper ethernet cabling technology
- 1000BASE-T/100BASE-TX/10BASE-T
- Full duplex
- Yes
- Jumbo frames support
- Yes
- Networking standards
- IEEE 802.1p/IEEE 802.3/IEEE 802.3ab/IEEE 802.3af/IEEE 802.3at/IEEE 802.3u/IEEE 802.3x
- Auto MDI/MDI-X
- Yes
- Rack mounting
- Yes
- 10G support
- No
- Basic switching RJ-45 Ethernet ports quantity
- 8
- Basic switching RJ-45 Ethernet ports type
- Gigabit Ethernet (10/100/1000)
- Power over Ethernet (PoE)
- Yes
- Gigabit Ethernet (copper) ports quantity
- 8
- MAC address table
- 4000 entries
- Store-and-forward
- Yes
- Jumbo frames
- 16000
- Flow control support
- Yes
- Packet buffer memory
- 1.5 MB
- Total Power over Ethernet (PoE) budget
- 153 W
- Cable types supported
- Cat3/Cat4/Cat5/Cat5e
- Stackable
- No
- Rack mount kit
- Yes
- Half duplex
- Yes
- Maximum cable length
- 100 m
- Power over Ethernet plus (PoE+) ports quantity
- 8
- MAC address auto-aging supported
- Yes
- MAC address auto-learning supported
- Yes
Specific References
- EAN
- 6935364086770
