MIKROTIK Access Point IEEE 802.11b IEEE 802.11g IEEE 802.11n 1xRJ45 RBCAPL-2ND

Other features

Depth

20 mm

Height

88 mm

Width

52 mm

Unit Box Width

0.095

Unit Box Length

0.16

Unit Box Height

0.05

Category Code

WAP

Model name

cAP lite // RBcAPL-2nD

Antenna Type

Internal

Unit Calculated Volume

0.0009555 cubm

Unit Calculated Weight

0.231 kg

Units per Shipping Box

20

Units per Pallet

500

Summary

Mikrotik cAP lite. 2.4 GHz, Maximum data transfer rate: 54 Mbit/s, Ethernet LAN data rates: 10,100 Mbit/s. Power over Ethernet (PoE). Product colour: White. Power consumption (max): 4 W

Product colour

White

AC input voltage

10 - 60 V

DC-in jack

Yes

Power consumption (max)

4 W

Operating temperature (T-T)

-40 - 70 °C

Harmonized System (HS) code

85176990

Ethernet LAN (RJ-45) ports

1

Operating system installed

RouterOS

Ethernet LAN data rates

10/100 Mbit/s

Reset button

Yes

Internal memory

64 MB

USB connector type

Micro-USB

Built-in processor

Yes

Internal

No

Maximum data transfer rate

54 Mbit/s

Networking standards

IEEE 802.11b/IEEE 802.11g/IEEE 802.11n/IEEE 802.3af/IEEE 802.3at

Output voltage

24 V

Flash memory

16 MB

Power over Ethernet (PoE)

Yes

Receiver sensitivity

-96, -89, -93, -74, -71

Antenna gain level (max)

1.5 dBi

2.4 GHz

Yes

5 GHz

No

Placement

Ceiling,Wall
