DAHUA Switch DH-CS4005-4ET1GT-36 Switch layer L2 4xRJ-45 ports RJ-45 Ports Type Fast Ethernet (10/100) 1xGigabit Ethernet (copp

Specification

Housing material

Metal

Other features

Depth

115 mm

Height

27 mm

Width

84 mm

Unit Box Width

0.115

Unit Box Length

0.195

Unit Box Height

0.085

Category Code

SWI

Model name

CS4005-4ET1GT-36

Switch type

Managed

Switching capacity

2.8 Gbit/s

Forwarding rate

2.08 Mpps

Power source

DC/PoE

Unit Calculated Volume

0.00273 cubm

Unit Calculated Weight

0.75 kg

Units per Shipping Box

12

Summary

Dahua Technology CS4005-4ET1GT-36. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 5. MAC address table: 2000 entries, Switching capacity: 2.

Product colour

Blue

Package depth

195 mm

Package height

83 mm

Package weight

720 g

Package width

114 mm

Cables included

AC

Input current

0.8 A

Operating relative humidity (H-H)

10 - 90 %

Operating temperature (T-T)

-10 - 55 °C

Storage relative humidity (H-H)

5 - 95 %

Quick start guide

Yes

Weight

200 g

Wall mountable

Yes

Storage temperature (T-T)

-40 - 70 °C

Mean time between failures (MTBF)

2037751.2 h

LED indicators

Yes

Ethernet LAN data rates

10,100,1000 Mbit/s

Reset button

Yes

Power supply included

Yes

Jumbo frames support

Yes

Networking standards

IEEE 802.1Q/IEEE 802.3/IEEE 802.3ab/IEEE 802.3af/IEEE 802.3at/IEEE 802.3az/IEEE 802.3u/IEEE 802.3x

Power connector

DC-in jack

Rack mounting

No

10G support

No

Basic switching RJ-45 Ethernet ports quantity

5

Basic switching RJ-45 Ethernet ports type

Gigabit Ethernet (10/100/1000)

Power over Ethernet (PoE)

Yes

Gigabit Ethernet (copper) ports quantity

1

MAC address table

2000 entries

Jumbo frames

9216

Flow control support

Yes

Packet buffer memory

4 MB

Fast Ethernet (copper) ports quantity

4

Power over Ethernet (PoE) ports quantity

4

Total Power over Ethernet (PoE) budget

36 W

DC input voltage

53 V

Switch layer

L2

Port mirroring

Yes

Web-based management

Yes

Loop protection

Yes

Broadcast storm control

Yes

VLAN support

Yes

Number of VLANs

32

DHCP features

DHCP client

Cloud-managed

Yes

Multicast support

Yes

IP-MAC-Port binding

Yes
