1449935
Other features
- Depth
- 440 mm
- Height
- 43.65 mm
- Width
- 163.85 mm
- Unit Box Width
- 0.275
- Unit Box Length
- 0.52
- Unit Box Height
- 0.11
- Category Code
- SWI
- Model name
- DH-SG4020
- Form Factor
- 1U
- Switch type
- Managed
- Switching capacity
- 56 Gbit/s
- Forwarding rate
- 29.76 Mpps
- Power source
- DC
- Unit Calculated Volume
- 0.01864 cubm
- Unit Calculated Weight
- 2.95 kg
- Units per Shipping Box
- 4
- Summary
- Dahua Technology SG4020. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 18, Console port: RJ-45. Full duplex. MAC address table: 8000 entrie
- Product colour
- Black
- Package depth
- 520 mm
- Package height
- 107 mm
- Package weight
- 2250 g
- Package width
- 271 mm
- Sustainability compliance
- Yes
- Power consumption (max)
- 24 W
- Operating relative humidity (H-H)
- 10 - 90 %
- Operating temperature (T-T)
- -10 - 55 °C
- Storage relative humidity (H-H)
- 5 - 95 %
- Compliance certificates
- CE
- Weight
- 1570 g
- Storage temperature (T-T)
- -40 - 75 °C
- Mean time between failures (MTBF)
- 467125.73 h
- LED indicators
- Yes
- Ethernet LAN data rates
- 10,100,1000 Mbit/s
- Reset button
- Yes
- Power supply included
- Yes
- Copper ethernet cabling technology
- 1000BASE-T/100BASE-TX/10BASE-T
- Full duplex
- Yes
- Jumbo frames support
- Yes
- Networking standards
- IEEE 802.1x/IEEE 802.3/IEEE 802.3ab/IEEE 802.3ad/IEEE 802.3u/IEEE 802.3x/IEEE 802.3z
- Rack mounting
- Yes
- 10G support
- No
- Basic switching RJ-45 Ethernet ports quantity
- 18
- Basic switching RJ-45 Ethernet ports type
- Gigabit Ethernet (10/100/1000)
- Power over Ethernet (PoE)
- No
- Gigabit Ethernet (copper) ports quantity
- 18
- MAC address table
- 8000 entries
- Jumbo frames
- 10000
- Flow control support
- Yes
- Packet buffer memory
- 4.1 MB
- DC input voltage
- 12 V
- Switch layer
- L2
- Quality of Service (QoS) support
- Yes
- IGMP snooping
- Yes
- Web-based management
- Yes
- Link aggregation
- Yes
- VLAN support
- Yes
- Virtual LAN features
- Port-based VLAN/Tagged VLAN
- Number of VLANs
- 4000
- Fanless
- Yes
- SFP module slots quantity
- 2
- Spanning tree protocol
- Yes
- Console port
- RJ-45
- DHCP features
- DHCP client/DHCP server/DHCP snooping
- Cloud-managed
- No
- Multicast support
- Yes
Specific References
- EAN
- 6923172593948
