1449932
Specification
- Housing material
- Steel
Other features
- Depth
- 240 mm
- Height
- 28 mm
- Width
- 104 mm
- Unit Box Width
- 0.24
- Unit Box Length
- 0.315
- Unit Box Height
- 0.08
- Category Code
- SWI
- Model name
- DH-SG4010-2F
- Switch type
- Managed
- Switching capacity
- 20 Gbit/s
- Forwarding rate
- 14.88 Mpps
- Power source
- DC
- Unit Calculated Volume
- 0.007659 cubm
- Unit Calculated Weight
- 1.18 kg
- Units per Shipping Box
- 12
- Summary
- Dahua Technology SG4010-2F. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8, Console port: RJ-45. Full duplex. MAC address table: 8000 entr
- Product colour
- Black
- Package depth
- 316 mm
- Package height
- 82 mm
- Package weight
- 1040 g
- Package width
- 240 mm
- Input current
- 1 A
- Sustainability compliance
- Yes
- Power consumption (max)
- 12 W
- Operating relative humidity (H-H)
- 5 - 95 %
- Operating temperature (T-T)
- -10 - 55 °C
- Compliance certificates
- CE
- Weight
- 640 g
- Wall mountable
- Yes
- Mean time between failures (MTBF)
- 2322286.99 h
- LED indicators
- Yes
- Ethernet LAN data rates
- 10,100,1000 Mbit/s
- Reset button
- Yes
- Copper ethernet cabling technology
- 1000BASE-T/100BASE-TX/10BASE-T
- Management protocols
- SNMP V1/V2C/V3
- Full duplex
- Yes
- Jumbo frames support
- Yes
- Networking standards
- IEEE 802.1p/IEEE 802.1Q/IEEE 802.1x/IEEE 802.3/IEEE 802.3ab/IEEE 802.3ad/IEEE 802.3u/IEEE 802.3x/IEEE 802.3z
- Rack mounting
- No
- 10G support
- No
- Basic switching RJ-45 Ethernet ports quantity
- 8
- Basic switching RJ-45 Ethernet ports type
- Gigabit Ethernet (10/100/1000)
- Power over Ethernet (PoE)
- No
- Gigabit Ethernet (copper) ports quantity
- 8
- MAC address table
- 8000 entries
- Jumbo frames
- 9000
- Flow control support
- Yes
- Packet buffer memory
- 4.1 MB
- Uplink ports quantity
- 2
- DC input voltage
- 12 V
- Switch layer
- L2
- Quality of Service (QoS) support
- Yes
- IGMP snooping
- Yes
- Web-based management
- Yes
- Link aggregation
- Yes
- VLAN support
- Yes
- Virtual LAN features
- Port-based VLAN/Tagged VLAN
- Number of VLANs
- 4000
- Fanless
- Yes
- SFP module slots quantity
- 2
- Spanning tree protocol
- Yes
- Fiber ethernet cabling technology
- 1000BASE-X
- Console port
- RJ-45
- DHCP features
- DHCP client
- Cloud-managed
- No
- Multicast support
- Yes
- Access Control List (ACL)
- Yes
Specific References
- EAN
- 6923172597670
