MSI Mainboard AMD X870E SAM5 ATX Memory DDR5 X870EGAMINGPLUSWIFI

Сеть

Bluetooth

Yes

Другие свойства

Depth

243.84 mm

Width

304.8 mm

Unit Box Width

0.27

Unit Box Length

0.24

Unit Box Height

0.07

Category Code

MBA

Model

X870E GAMING PLUS WIFI

Bluetooth version

5.4

Unit Calculated Volume

0.008014 cubm

Unit Calculated Weight

2.18 kg

Units per Shipping Box

5

Summary

MSI X870E GAMING PLUS WIFI. Processor manufacturer: AMD, Processor socket: Socket AM5, Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series. Supported memory types: DDR5-SDRAM, Maximum internal memory: 256 GB, M

Product colour

Black

HDMI ports quantity

1

HDMI version

2.1

Cables included

SATA

Screws included

Yes

Headphone outputs

1

Wi-Fi

Yes

Microphone in

Yes

Ethernet LAN (RJ-45) ports

1

Ethernet LAN

Yes

Wi-Fi standards

802.11a/802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac)/Wi-Fi 6 (802.11ax)/Wi-Fi 6E (802.11ax)/Wi-Fi 7 (802.11be)

Maximum resolution

3840 x 2160 pixels

Parallel processing technology support

Not supported

USB 2.0 ports quantity

4

ATX Power connector (24-pin)

Yes

EPS power connector (8-pin)

Yes

Processor manufacturer

AMD

Maximum internal memory

256 GB

Memory channels

Dual-channel

On-board graphics card

No

Top Wi-Fi standard

Wi-Fi 7 (802.11be)

Motherboard chipset

AMD X870E

Number of SATA III connectors

4

PCI Express x1 slots

1

Audio output channels

7.1 channels

PCI Express x16 (Gen 3.x) slots

3

Memory slots type

DIMM

Number of memory slots

4

Supported memory types

DDR5-SDRAM

Supported storage drive types

HDD

Motherboard form factor

ATX

Component for

PC

Compatible processor series

AMD Ryzen 7000 Series/AMD Ryzen 8000 Series/AMD Ryzen 9000 Series

Processor socket

Socket AM5

Supported processor sockets

Socket AM5

Unbuffered memory

Yes

RAID levels

0/1/10/5

RAID support

Yes

CPU fan connector

Yes

Front panel audio connector

Yes

Front panel connector

Yes

Number of chassis fan connectors

6

Number of CPU fan connectors

1

Number of RGB LED pin headers

3

RGB LED pin header

Yes

TPM connector

Yes

USB 2.0 connectors

6

USB 3.2 Gen 1 (3.1 Gen 1) connectors

4

Ethernet interface type

5 Gigabit Ethernet

Motherboard chipset family

AMD

Number of M.2 (M) slots

3

Antenna included

Yes

Number of water pump connectors

1

Chassis intrusion connector

Yes

Number of COM connectors

1

USB 3.2 Gen 2 (3.1 Gen 2) connectors

1

ECC сompatibility

ECC & Non-ECC
