MSI Mainboard Intel H810 LGA1851 Micro-ATX Memory DDR5 Memory slots 2 PROH810M-B

Другие свойства

Depth

243.84 mm

Width

220 mm

Unit Box Width

0.28

Unit Box Length

0.255

Unit Box Height

0.065

Category Code

MBI

Model

PRO H810M-B

Unit Calculated Volume

0.005751 cubm

Unit Calculated Weight

1.1 kg

Units per Shipping Box

10

Summary

MSI PRO H810M-B. Processor manufacturer: Intel, Processor socket: LGA 1851 (Socket V1), Compatible processor series: Intel Core Ultra (Series 2). Supported memory types: DDR5-SDRAM, Maximum internal memory: 128 GB, ECC сompatibility: Non-ECC. Supported s

DisplayPort version

1.4

DisplayPorts quantity

1

HDMI ports quantity

1

HDMI version

2.1

Cables included

SATA

Windows operating systems supported

Windows 11

Ethernet LAN (RJ-45) ports

1

Ethernet LAN

Yes

USB 2.0 ports quantity

4

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity

2

ATX Power connector (24-pin)

Yes

Processor manufacturer

Intel

Maximum internal memory

128 GB

Audio chip

Realtek ALC897

Motherboard chipset

Intel H810

Number of SATA III connectors

4

PCI Express x1 slots

2

PCI Express x16 (Gen 5.x) slots

1

Audio output channels

7.1 channels

Number of memory slots

2

Supported memory types

DDR5-SDRAM

Supported storage drive types

HDD & SSD

Supported memory clock speeds

4800/6400 MHz

Motherboard form factor

Micro ATX

Component for

PC

Compatible processor series

Intel Core Ultra (Series 2)

Processor socket

LGA 1851 (Socket V1)

Supported storage drive interfaces

SATA III

CPU fan connector

Yes

Front panel audio connector

Yes

Number of chassis fan connectors

2

Number of RGB LED pin headers

1

RGB LED pin header

Yes

TPM connector

Yes

USB 2.0 connectors

4

Ethernet interface type

2.5 Gigabit Ethernet

Motherboard chipset family

Intel

Number of M.2 (M) slots

1

12V power connector

Yes

USB 3.2 Gen 2 (3.1 Gen 2) connectors

3

Audio connector

Yes

ECC сompatibility

Non-ECC

Power fan connector

Yes

CD/AUX audio in

Yes
