MSI Mainboard Intel Z790 LGA1700 ATX Memory DDR5 Memory slots 4 1xPCI-Express 3.0 1x 2xPCI-Express 5.0 16x 4xM.2 1xHDMI 1xDispl

Сеть

Bluetooth

Yes

Другие свойства

Depth

304.8 mm

Width

243.84 mm

Unit Box Width

0.275

Unit Box Length

0.345

Unit Box Height

0.075

Category Code

MBI

Model

MAG Z790 TOMAHAWK WIFI

Bluetooth version

5.3

Unit Calculated Volume

0.007116 cubm

Unit Calculated Weight

1.88 kg

Units per Shipping Box

1

Summary

MSI MAG Z790 TOMAHAWK WIFI. Processor manufacturer: Intel, Processor socket: LGA 1700, Compatible processor series: Intel® Celeron®, Intel® Pentium® Gold. Supported memory types: DDR5-SDRAM, Maximum internal memory: 192 GB, Memory channels: Dual-chann

Product colour

Black

DisplayPort version

1.4

DisplayPorts quantity

1

HDMI ports quantity

1

HDMI version

2.1

Cables included

SATA

Wi-Fi

Yes

Windows operating systems supported

Windows 10 x64/Windows 11 x64

Ethernet LAN (RJ-45) ports

1

Ethernet LAN

Yes

Wi-Fi standards

802.11a/802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac)/Wi-Fi 6 (802.11ax)

Parallel processing technology support

Not supported

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

4

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity

1

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity

4

USB 3.2 Gen 2x2 Type-C ports quantity

1

Processor manufacturer

Intel

Maximum internal memory

192 GB

Memory channels

Dual-channel

Top Wi-Fi standard

Wi-Fi 6 (802.11ax)

Motherboard chipset

Intel Z790

Number of SATA III connectors

7

S/PDIF out port

Yes

PCI Express x16 (Gen 5.x) slots

2

Audio output channels

7.1 channels

Number of memory slots

4

Supported memory types

DDR5-SDRAM

Supported storage drive types

HDD & SSD

Supported memory clock speeds

4800/5200/5400/5600/5800/6000/6200/6400/6600/6800/7000/7200 MHz

Motherboard form factor

ATX

Component for

PC

Compatible processor series

Intel® Celeron®/Intel® Pentium® Gold

Processor socket

LGA 1700

Supported processor sockets

LGA 1700

Supported memory clock speed (max)

7200 MHz

Unbuffered memory

Yes

RAID levels

0/10/5

RAID support

Yes

Supported storage drive interfaces

M.2,PCI Express

CPU fan connector

Yes

Front panel audio connector

Yes

Front panel connector

Yes

RGB LED pin header

Yes

TPM connector

Yes

USB 2.0 connectors

2

USB 3.2 Gen 1 (3.1 Gen 1) connectors

2

Ethernet interface type

2.5 Gigabit Ethernet

Motherboard chipset family

Intel

Number of M.2 (M) slots

4

ACPI version

6.4

BIOS memory size

256 Mbit

BIOS type

UEFI AMI

System Management BIOS (SMBIOS) version

3.5

Chassis intrusion connector

Yes

USB 3.2 Gen 2 (3.1 Gen 2) connectors

1

Maximum internal memory supported by processor

192 GB

PCI Express x1 (Gen 4.x) slots

1

ECC сompatibility

Non-ECC
