1451042
Другие свойства
- Depth
- 193 mm
- Width
- 220 mm
- Unit Box Width
- 0.24
- Unit Box Length
- 0.28
- Unit Box Height
- 0.06
- Category Code
- MBI
- Model
- H810M-H
- Unit Calculated Volume
- 0.0044225 cubm
- Unit Calculated Weight
- 0.897 kg
- Units per Shipping Box
- 20
- Summary
- Asrock H810M-H. Processor manufacturer: Intel, Processor socket: LGA 1851 (Socket V1), Compatible processor series: Intel Core Ultra (Series 2). Supported memory types: DDR5-SDRAM, Maximum internal memory: 128 GB, Memory slots type: DIMM. Supported storag
- High Dynamic Range (HDR) supported
- Yes
- Product colour
- Black
- HDCP
- Yes
- HDCP version
- 2.3
- HDMI ports quantity
- 1
- HDMI version
- 2.1
- Cables included
- SATA
- Screws included
- Yes
- Certification
- FCC, CE, ErP/EuP ready
- Wi-Fi
- No
- Windows operating systems supported
- Windows 11 x64
- Microphone in
- Yes
- Ethernet LAN (RJ-45) ports
- 1
- Ethernet LAN
- Yes
- Maximum resolution
- 3840 x 2160 pixels
- USB 2.0 ports quantity
- 4
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
- 4
- Number of storage drives supported
- 5
- ATX Power connector (24-pin)
- Yes
- Processor manufacturer
- Intel
- Maximum internal memory
- 128 GB
- Memory channels
- Dual-channel
- Audio chip
- Realtek ALC897
- Motherboard chipset
- Intel H810
- LAN controller
- Realtek RTL8111H
- Number of SATA III connectors
- 4
- Line-in
- Yes
- Audio output channels
- 7.1 channels
- PS/2 ports quantity
- 1
- Memory slots type
- DIMM
- Number of memory slots
- 2
- Supported memory types
- DDR5-SDRAM
- Supported storage drive types
- HDD & SSD
- Motherboard form factor
- Micro ATX
- Component for
- PC
- Compatible processor series
- Intel Core Ultra (Series 2)
- Processor socket
- LGA 1851 (Socket V1)
- Supported processor sockets
- LGA 1851
- Supported memory clock speed (max)
- 6400 MHz
- Unbuffered memory
- Yes
- Supported storage drive interfaces
- M.2,SATA III
- CPU fan connector
- Yes
- Front panel audio connector
- Yes
- Number of chassis fan connectors
- 1
- Number of CPU fan connectors
- 1
- Number of RGB LED pin headers
- 1
- RGB LED pin header
- Yes
- TPM connector
- Yes
- USB 2.0 connectors
- 2
- USB 3.2 Gen 1 (3.1 Gen 1) connectors
- 2
- Ethernet interface type
- Gigabit Ethernet
- Motherboard chipset family
- Intel
- 1st M.2 highest PCI Express generation
- 4.0
- 1st M.2 largest key size
- 2280
- Number of M.2 (M) slots
- 1
- PCI Express x16 (Gen 4.x) slots
- 1
- BIOS memory size
- 256 Mbit
- BIOS type
- UEFI AMI
- 12V power connector
- Yes
- PCI Express x1 (Gen 4.x) slots
- 1
- ECC сompatibility
- ECC & Non-ECC
Особые артикулы
- EAN
- 4711581490833
